◾ Capacitive Touch Key
DIMENSION
SPECIFICATION
|
Power Input |
DC 10V ~ 32V |
|
Power Consumption |
Max 30 Watt |
|
Video System |
NTSC / PAL compatible |
|
Panel |
7 Inch Digital |
| Panel Ratio | 16:9 |
| Panel Brightness | 500cd/㎡ |
| Panel Resolution | 800(H) × 3(RGB) × 480(V) pixels |
|
Display Mode |
Single, Split, Triple, Quad, PIP |
| Camera Input (4 Channel) | Mini 4Pin DIN or 4Pin IP Connector (1Vp-p 75Ω) |
| Operating Temperature | -30℃ ~ 75℃ (-22°F ~ 167°F) |
| IP Rating | IP65 |
| Vibration | 7G |
| Weight | 580g (Monitor Only) |
| Dimensions | 196(W) × 124(H) × 47(D) mm |
| 7.7(W) × 4.8(H) × 1.9(D) inch | |
| OSG Control |
Day and Night Sensor Speed Switch Auto Scan Bright, Contrast, Color, Tint Adjust Mirror / Normal, Up / Down, Day / Night Mode ※ Individual Control per Channel available |
