vehicles
◾Optimized to Delivery Trucks
◾Easty to Install
DIMENSION
SPECIFICATION
|
Image Type |
2.1 Mega Pixels CMOS Sensor |
|
Image Size |
1/2.7 Inch |
|
Angle of View |
Diagonal Angle : 153º (Degree) |
|
Horizontal Angle : 132º (Degree) |
|
|
Vertical Angle : 70º (Degree) |
|
|
Synchronization |
Internal |
| Horizontal Resolution | More than 1,000TV Lines (A·HD) |
| Minimum Illumination | 0 Lux without IR LED |
| Signal to Noise Ratio | Better than 50dB (at AGC off) |
|
Power Input |
DC 12V |
| Operating Temperature | -40℃ ~ 70℃ (-40°F ~ 158°F) |
| IP Rating | IP69K |
| Vibration | 7G |
| Housing | Body : Aluminium Bracket : Plastic |
| Weight | 155g (Camera Only) |
| Dimensions | 40(W) × 42(H) × 48(D)mm |
